Zeer belangrijke eigenschappen
- Verminderd motorgewicht
- Open lichaamsontwerp voor betere passieve hittedissipatie
- Verenigbaarheid voor propellerinstallatie
- Standarization van motor opzettende gaten
- Herstelbaar
- Gemaximaliseerde prestaties
- Lage machtsconsumptie
- Ontworpen voor 12S-voltage
Specificaties
|
RPM/V
|
85KV
|
|
Configuratie
|
36N40P
|
|
Statorgrootte
|
81x16 mm
|
|
Motorafmetingen
|
88.6 x 33 mm
|
|
Schachtdiameter
|
15 mm
|
|
Maximumstroom
|
41.3 A
|
|
Motorgewicht
|
450 g
|
|
Product In dozen gedaan Gewicht
|
650 g
|
|
Maximumduw
|
12400g (12S)
|
|
Efficiency bij 3500 g Duw
|
10.5g/W
|
|
Hittedissipatie
|
Passief
|
|
Evenwichtige rotor
|
Ja
|
|
Op zwaar werk berekend Ontwerp
|
Nr
|
|
Graad van Bescherming
|
Wateproof
|
|
Propeller Opzettende Gaten
|
4xM3 Ø20 mm
|
|
Motor Opzettende Gaten
|
4xM3 Ø30/Ø50mm 4xM4 Ø32mm
|
|
Draad
|
Het winden breidde 150 mm uit
|
|
Propelleradapter
|
1pc
|
|
Extra Toebehoren
|
3x krimpt de Vastgestelde 3x Hitte van de kogelschakelaar Buizen
4x m3 10mm 4x M4 10mm 4x M3 14mm
2x Dekking 1 van de koolstofsteun x-MAD Stickers
|
|
AANBEVELINGEN
|
|
MAD 8116 EEE
|
85KV
|
100KV
|
|
Propellergrootte
|
29“ - 32“ (12S)
|
26“ - 29“ (12S)
|
|
Startgewicht
|
4000-6000 g/rotor (12S)
|
3500-5000 g/rotor (12S)
|
Testparameters
|
Motor
|
Steun
|
Volts
(v)
|
Gaspedaal
|
Ampèren (a)
|
Duw (g)
|
T/min
|
Watts (W)
|
Efficiency (g/W)
|
Torsie (N*M)
|
Temperatuur (°C)
|
|
MAD8116
85KV
|
30105
|
40
|
10%
|
2.5
|
1400
|
1332
|
100
|
14. 00
|
0. 72
|
40 °C
|
|
20%
|
5
|
2410
|
1704
|
200
|
12. 05
|
1. 12
|
|
30%
|
7.5
|
3380
|
1987
|
300
|
11. 27
|
1. 44
|
|
40%
|
10
|
4040
|
2182
|
400
|
10. 10
|
1. 75
|
|
50%
|
12.5
|
4830
|
2360
|
500
|
9. 66
|
2. 02
|
|
60%
|
15
|
5400
|
2504
|
600
|
9. 00
|
2. 29
|
|
70%
|
17.5
|
6060
|
2641
|
700
|
8. 66
|
2. 53
|
|
80%
|
20
|
6830
|
2781
|
800
|
8. 54
|
2. 75
|
|
90%
|
22.5
|
7200
|
2871
|
900
|
8. 00
|
2. 99
|
|
100%
|
25
|
7860
|
2967
|
1000
|
7. 86
|
3. 22
|
|
30105
|
48
|
10%
|
3.4
|
2000
|
1570
|
163.2
|
12. 25
|
0. 99
|
52°C
|
|
20%
|
6.8
|
3430
|
2017
|
326.4
|
10.51
|
1. 55
|
|
30%
|
10.2
|
4620
|
2322
|
489.6
|
9. 44
|
2.01
|
|
40%
|
13.6
|
5690
|
2560
|
652.8
|
8. 72
|
2. 44
|
|
50%
|
17
|
6720
|
2771
|
816
|
8. 24
|
2.81
|
|
60%
|
20.4
|
7620
|
2942
|
979.2
|
7. 78
|
3. 18
|
|
70%
|
23.8
|
8450
|
3083
|
1142.4
|
7. 40
|
3. 54
|
|
80%
|
27.2
|
9230
|
3227
|
1305. 6
|
7. 07
|
3. 86
|
|
90%
|
30.6
|
10090
|
3350
|
1468. 8
|
6. 87
|
4. 19
|
|
100%
|
33.4
|
10660
|
3436
|
1603. 2
|
6. 65
|
4. 46
|
|
32105
|
40
|
10%
|
3
|
1410
|
1261
|
120
|
11. 75
|
0,91
|
46°C
|
|
20%
|
6
|
2760
|
1663
|
240
|
11. 50
|
1. 38
|
|
30%
|
9
|
3700
|
1900
|
360
|
10. 28
|
1.81
|
|
40%
|
12
|
4650
|
2098
|
480
|
9. 69
|
2. 18
|
|
50%
|
15
|
5580
|
2278
|
600
|
9. 30
|
2. 52
|
|
60%
|
18
|
6300
|
2414
|
720
|
8. 75
|
2. 85
|
|
70%
|
21
|
7020
|
2528
|
840
|
8. 36
|
3. 17
|
|
80%
|
24
|
7720
|
2640
|
960
|
8. 04
|
3. 47
|
|
90%
|
27
|
8300
|
2745
|
1080
|
7. 69
|
3. 76
|
|
100%
|
30.4
|
9230
|
2853
|
1216
|
7. 59
|
4. 07
|
|
32105
|
48
|
10%
|
4.2
|
2280
|
1533
|
201.6
|
11.31
|
1. 26
|
67°C
|
|
20%
|
8.4
|
4040
|
1933
|
403.2
|
10. 02
|
1. 99
|
|
30%
|
12.6
|
5400
|
2245
|
604.8
|
8. 93
|
2. 57
|
|
40%
|
16.8
|
6730
|
2482
|
806.4
|
8. 35
|
3. 10
|
|
50%
|
21
|
8000
|
2676
|
1008
|
7. 94
|
3. 60
|
|
60%
|
25.2
|
8970
|
2837
|
1209-6
|
7. 42
|
4. 07
|
|
70%
|
29.4
|
9960
|
2981
|
1411.2
|
7. 06
|
4. 52
|
|
80%
|
33.6
|
10800
|
3107
|
1612.8
|
6. 70
|
4. 96
|
|
90%
|
37.8
|
11520
|
3206
|
1814.4
|
6. 35
|
5. 40
|
|
100%
|
41.3
|
12400
|
3274
|
1982. 4
|
6. 26
|
5. 78
|
